E-Bike Key Specs
Battery
Yamaha 720Wh
Display
Interface X
Motor
Yamaha PW X3
Range
30-160 miles
Specifications
General Bike Specifications
Frame Aluminium, through axle M12 (1.00) x 148mm, disc brake Post Mount
Forks RockShox Yari RC, air, aluminum shaft 1 1/8" - 1 1/2" tapered, thru-axle Boost, Travel: 160mm
Rear Shock RockShox Deluxe Select Plus, air, Travel: 160mm
Brakes Magura MT5, 203mm
Shifters Shimano Deore SLX M7100
Rear Mech Shimano SLX M7100, 12-speed
Cassette Shimano M6100, 10-51 teeth
Chain Shimano M6100
Wheelset WTB ST i30 TCS, double-walled rim
Tyres Maxxis Minion DHF, 65-622 (Front) / Maxxis Minion DHR II, 66-584 (Rear)
Handlebars Haibike Components TheBar +++ 780mm
Stem Haibike Components TheStem +++, Bar bore:31.8mm
Headset Acros BlockLock
Seatpost Dropper-Post Remote, telescope, 34.9mm,aluminium
Saddle Selle Royal Vivo
Weight 25 kg
Electric Bike Specifications
Battery Yamaha InTube 720Wh
Display Yamaha Interface X
Motor Yamaha PW-X3, 250W, 85Nm, 25km/h
Range 30-160 miles of power-assisted range, depending on terrain
