Haibike AllMtn 3 2023 Electric Bike

Haibike Electric Bikes

Haibike AllMtn 3 (Alloy)

£3,499.00 £4,799.00 Save £1,300.00


Frame Size: S 41cm

E-Bike Key Specs


Yamaha 720Wh


Display A


Yamaha PW X3


30-160 miles

View in store

E-Bike Highlights


Haibike AllMtn 3 2023 Electric Bike Rider Review

The brand new AllMtn 3 2023 is the entry level Yamaha driven all mountain and trail bike for the new Haibike model year and offers some of the best componentry in the now incredibly vast AllMtn Range at an ultra competitive price. A brand new all alloy frame built around new Yamaha PW-X3 motor and 720Wh battery, the new AllMtn 3 eMTB is designed to do absolutely everything in one neat, eye-catching package.

Although toward the entry level price range in the AllMtn line up for the 2023 model year, the AllMtn 3 is a very capable machine and will be just as at home in the hands of a novice rider as it will a competent rider looking for an easier route to the top!

Our 5 point review...


Lightweight and robust alloy frame


Yamaha's biggest 720Wh electric bike battery


12 speed Shimano SLX 10-51t gearing


Yamaha's most powerful PW-X3 motor with 85Nm torque output


Large, easy to read Yamaha Side Switch display


Haibike AllMtn 3 2023 Yamaha PW X3 Motor
Haibike AllMtn 3 2023 Yamaha 720Wh Battery

New drive system for 2023..

Featuring the Yamaha PW-X3 motor system, Side Switch display and the 720Wh InTube battery cleverly incorporated within the frame, the new 2023 Haibike AllMtn 3 is a great contender for those just starting out in the world of electric biking, or looking to go further.

Haibike AllMtn 3 2023 RockShox Gold 35 Forks
Haibike AllMtn 3 2023 Shimano MT420 Disc Brakes

Full Rockshox suspension..

Whatever mountain you need to scale, the AllMtn 3 with its Rockshox 35 Gold forks and Rockshox Deluxe Select rear shock can soak it up in 160mm of plush travel.

Offering multi-way adjustment and tuning allows you to tailor your setup to your weight, riding style and terrain with a complete 160mm of travel front and rear.

Haibike AllMtn 3 2023 Shimano Deore Gears

Brakes & Gears

Continuing the theme of high specification componentry at a great value price point, the Haibike AllMtn 3 is fitted with Shimano MT420 brakes.

These twin piston brakes offer a great amount of braking force, making them the go to option for manufacturers looking to pull an eBike to a stop on even the steepest and most technical descents.

Paired with monster 203mm discs up front and 203mm at the rear, the full Shimano setup is and easily maintained but ultra powerful.

12 speed gearing has become the "go to" choice for eMTB manufacturers and 2023 Haibike AllMtn 3 is no different. It gets its 12 gears for 2023 in the form of the Shimano M6100 SLX group set.

Its super wide ratio 10-51T cassette really takes the sting out of the long ascents, without holding you back in top speed on open ground and downhill sections and offers a useful gear for every scenario, regardless of terrain.

The Shimano trigger shifters offers fast, precise shifting with minimal chain slap, leaving you to concentrate on the trail ahead. .

Haibike AllMtn 3 2023 Shimano MT420 Disc Brakes

Shimano MT420 brakes are a strong set of anchors and will pull the AllMtn 3 2023 to a stop quickly, even in adverse conditions.

Haibike AllMtn 3 2023 Shimano Deore Gears

Shimano Deore 12 speed gearing is simple to use and offers an exceptional ratio range only normally found on mountain bikes.

Haibike AllMtn 3 2023 Shimano Deore Shifter

Shimano Deore trigger shifters are smooth, easy to use and require little effort to quickly zip between gears.

Haibike AllMtn 3 2023 Maxxis Minion Tyres

Wheels & Tyres

Continuing the AllMtn model range trend, the AllMtn 3 also gets a "mullet" wheel set up with a 29" front and 27.5" rear in the form of WTB ST i30 rims on Shimano hubs.

The 2023 Haibike AllMtn 3 tyre setup offers a clue to its design purpose and are very much top level components on an entry level bike.

With a 2.5" Maxxis Minion DHF II up front and a 2.6" Maxxis Minion DHR II at the rear, these Tubeless Ready tyres are designed to be fast, precise and provide useful feedback on any terrain and can be set up tubeless when we build your new bike at just £49.99.

Haibike AllMtn 3 2023 Dropper Post

The bottom line..

The AllMtn 3, like most Haibike models is aggressively styled with a highly "angular" aesthetic. Offering full internal cable and hose routing including the factory fitted dropper post, everything is tucked neatly out of the way.

The low gloss finish is eye catching and shows off the incredible level of attention to detail in the overall build quality and component integration.


Haibike AllMtn 3 2023 Yamaha PW X3 Motor System

Yamaha PW-X3 and Side Switch display

The new Haibike AllMtn 3 2023 eBike features the latest Yamaha PW-X3 drive system. This brand new motor for 2023 offers 85Nm of torque and peaks at over 500w.

With 4 assistance modes, it can now provide up to 360% assistance in its highest power mode. Part of the brand new PW-X3 system for 2023, the AllMtn 3 also gets a new 720Wh battery.

Completely integrated into the frame, Haibike have neatly incorporated it into the downtube of the frame but with a key lock detachment, allowing it to be charged both on and off the bike.

The Side Switch display is incredibly simple to use, and offers immediate information on battery and assist levels viewable from its integrated screen and button system. The control buttons mounted to the left of the handlebars allow the user to toggle ride modes on-the-fly.

Haibike AllMtn 3 2023 Yamaha Side Switch Display

The Yamaha Side Switch is the most commonly used Yamaha display system and has all the features a rider needs in one neat package.

Haibike AllMtn 3 2023 Yamaha PW X3 Motor

The Yamaha motor system gets a new update for 2023 in the form of the PW-X3. With 85Nm, it has all the power you need to cover any terrain type.

Haibike AllMtn 3 2023 Yamaha 720Wh Battery

The AllMtn 3 2023 gets the new Yamaha 720Wh battery, offering up to 160 miles on a single charge.

Haibike AllMtn 3 2023 E-Bikeshop What's Included

What's included

Your new electric bike gets a full set-up by our workshop technicians ahead of delivery.

Your eBike will arrive with a user manual, keys (where applicable), charger & free follow up service (at our service center) within 3 months of delivery.

This electric bikes includes a 5yr warranty on the frame, 2yr warranty on all the electrics and 1yr warranty on the components. In the event of a problem, we handle all warranty claims via our dedicated support in-house.

E-Bikeshop is a UK Electric Bike Service Center and our in-house workshop is exclusively reserved for our own eBike customers. We have time to support the eBikes we sell.

Why choose E-Bikeshop?


General Bike Specifications

Frame Haibike Alloy frame

Forks RockShox 35 Gold RL, 160mm

Brakes Shimano MT420, 203mm

Shifters Shimano Deore M6100, 12-Speed

Rear Mech Shimano Deore M6100, 12-Speed

Cassette Shimano M6100, 12-Speed, 10-51t

Chain Shimano CN-M6100

Wheelset WTB ST i30 Rims on Shimano Hubs

Tyres Maxxis DHF 29x2.5" / Minion DHR II 27.5x2.6"

Handlebars Haibike TheBar 780mm

Stem Haibike TheStem, Alloy, 31.8mm

Headset A-Head, Alloy

Seatpost Haibike dropper post, 34.9mm

Saddle Selle Royal Vivo

Weight 26 kg

Electric Bike Specifications

Battery Yamaha InTube 720Wh

Display Yamaha Side Switch

Motor Yamaha PW-X3, 250W, 85Nm

Range 30-160 miles of power-assisted range, depending on terrain
