Scott Electric Bikes

Scott Axis eRIDE Evo Tour FS 2022

£5,699.00

Pre-order
Scott Axis eRIDE Evo Tour FS 2022


Frame Size: M 44cm

Battery

Bosch 750Wh

Display

Bosch Kiox 300

Motor

Bosch CX Gen 4

Range

30-160 miles

View in store

Why choose E-Bikeshop?

E-Bike Highlights

WHO IS THIS BIKE
SUITABLE FOR?

The Scott Axis eRIDE Tour FS 2022 is the bike that quite literally does it all.

Rarely does a manufacturer build something just as at home picking up the weekly shopping as it is on the forest trail or a long distance tour but Scott have managed exactly that with their new Axis ERIDE Tour.

A full suspension hybrid ebike for comfort and control on the roughest of terrain, driven by Bosch's most powerful motor and fed by their new 750Wh PowerTube battery.

Our 5 point review...

1

Advanced carbon fibre twin-mold lightweight frame

2

Longest range Bosch 750Wh electric bike battery

3

Offering the latest gen Shimano 11-speed gearing

4

Highest performing Bosch motor at 340% assistance

5

Full rider control with the new Bosch Kiox 300 display

Features

Scott Axis eRIDE Tour FS 2022 Shimano Hydraulic Brakes
Scott Axis eRIDE Tour FS 2022 Bosch Kiox 300 Display

One bike to do it all..

At the front, the Fox AWL 140mm forks are air adjustable for rider weight and have a three stage lockout. At the rear you'll find a Fox FLOAT eRIDE shock with matching travel, also attached to Scotts TwinLoc lockout system.

With one lever controlling both front and rear travel and lockout, you can make on the fly adjustments with a single lever press. Descend mode provides full front and rear travel and utilises the bikes full geometry for positive feedback and control.

Scott Axis eRIDE Tour FS 2022 Fox Float eRIDE Rear Suspension
Scott Axis eRIDE Tour FS 2022 Fox AWL 140mm Front Suspension

Total versatility..

Neatly hidden in the frame of the bike, and protected from the elements by a specially designed cover, the Fox Float rear shock with 140mm travel is perfectly set up for the Axis eRIDE Evo TOUR FS model, and will soak up the roughest of terrain with ease, and a firm focus on comfort and predictable handling.

Scott Axis eRIDE Tour FS 2022 Shimano XT 11 Speed Rear Derailleur

Brakes & Gears

The larger Shimano Deore MT520 twin piston brakes are from the top end of Shimano's parts shelf and offer supreme performance and modulation.

Larger twin piston brakes are a real bonus on heavier eBikes when braking downhill and the 203mm rotors increase stopping power and mean they won't overheat and suffer from extreme fade over longer descents.

The 2022 Scott Avis eRIDE Evo Tour FS eBike is equipped with the 12 speed Shimano Deore derailleur and shifter.

This group set uses the Shimano Micro Spline freehub body, which allows for a smaller 11t sprocket. This 10-12th gear has become the new standard on eMTBs.

The cassette offers a super wide range ratio 11-51t setup. With this exceptional level of ratio choice, there will be nothing you cant climb but without compromising top speed on flat ground.

Scott Axis eRIDE Tour FS 2022 Shimano MT520 Hydraulic Brakes

Faster piston retraction gives superior modulation and much greater fast & slow speed control.

Scott Axis eRIDE Tour FS 2022 Shimano XT Rear Derailleur

Shadow Plus rear derailleur keeps chain tension in check and chain slap to a minimum.

Scott Axis eRIDE Tour FS 2022 Shimano M8100 Trigger Shifters

The Rapid-Fire Plus shifters provide smooth but positive, on-the-fly shifting.

Scott Axis eRIDE Tour FS 2022 Snycros Saddle

Wheels & Tyres

Scott have used their own Syncros 29" MAXX tubeless ready wheelset rims, laced onto Formula hubs.

Onto the Syncros rims, Scott fit the Schwalbe G-One AllRound Performance 29x2.2" tyres.

Scott Axis eRIDE Tour FS 2022 Schwalbe G-One Allroad Tyres

The bottom line..

Having one bike to do absolutely everything offers unique value for those living in rural areas, where using the car isn't necessary, but having to tackle multiple terrain types is.

The Scott Axis eRIDE Evo Tour FS covers almost everything with absolute ease, and its upright seating position enables riders of any skill level to do it with relative ease.

The Scott Axis eRIDE Evo Tour FS covers almost everything with absolute ease, and its upright seating position enables riders of any skill level to do it with relative ease.

Power

Scott Axis eRIDE Tour FS 2022 Bosch Generation 4 Performance CX Motor

New Bosch CX, LED Remote & Kiox 300

The new 2022 Scott Axis Tour FS eBike features the latest Gen 4 Bosch Performance CX crank drive motor, with a brand new twist.

The recently updated 250w CX system now provides 85Nm of torque and peaks at 500w. With 4 assistance modes, it can now provide up to 340% assistance in Turbo mode. In addition, the new eMTB mode allows the user to set off in one assistance mode and clever sensor driven system will provide exactly the right amount of power right when you need it and less when you don't.

Part of the brand new "Smart System" 2022 Bosch Update, the new 2022 Scott Axis Tour FS features their new Bosch 'PowerTube' 750Wh battery. Completely integrated into the frame, the battery is fully removable, allowing it to be charged both on and off the bike.

The new Bosch Kiox 300 display is neat and super compact with a bright, intuitive LCD display screen and tailored around helping riders with their training. It can also be updated wirelessly via the new eBike Flow app.

Scott Axis eRIDE Tour FS 2022 Bosch Kiox 300 display

The new Bosch Kiox 300 display is neat and super compact with a bright, intuitive LCD display screen and tailored around helping riders with their training. It can also be updated wirelessly via the new eBike Flow app.

Scott Axis eRIDE Tour FS 2022 Bosch eBike LED Remote

The new Bosch eBike LED Remote keeps the rider in-tact with the ride assist mode at any moment during the ride, it's easy to read featuring a built-in ambient light sensor and ergonomic design for quick assist changes on-the-go.

Scott Axis eRIDE Tour FS 2022 Bosch PowerTube 750Wh battery

The Bosch PowerTube 750Wh battery neatly fits inside the frame. The whopping 750Wh battery is the latest in the Bosch eBike line-up offering the very longest range possible. It can be charged both in the bike or when removed.

What's included

Your new electric bike gets a full set-up by our workshop technicians ahead of delivery.

Your eBike will arrive with a user manual, keys (where applicable), charger & free follow up service (at our service center) within 3 months of delivery.

This electric bikes includes a 5yr warranty on the frame, 2yr warranty on all the electrics and 1yr warranty on the components. In the event of a problem, we handle all warranty claims via our dedicated support in-house.

E-Bikeshop is a UK Electric Bike Service Center and our in-house workshop is exclusively reserved for our own eBike customers. We have time to support the eBikes we sell.

Specifications

General Bike Specifications

Frame Alloy, Integrated Cables, 140mm

Forks Fox AWL, 140mm w/Remote Lockout

Rear Shock FOX Float eRIDE, Trunnion 140mm w/Remote Lockout

Brakes Shimano MT520 4-Piston, 203mm rotors

Shifters Shimano Deore M8130 Trigger 11-Speed

Rear Mech Shimano XT 11-Speed

Cassette Shimano LG600, 11-51t, 11-Speed

Chain KMC E11S 11-Speed

Wheelset Formula Hubs on Syncros MAXX Rims, TL Ready

Tyres Schwalbe G-One Allround Performance 29x2.25"

Handlebars Syncros 3.0, 20mm rise, 720mm

Stem Syncros FL3.0 with Front light & Kiox mount

Headset Acros Tapered Headset

Seatpost Syncros FL3.0, 31.6mm

Saddle Syncros Capilano

Weight 28 kg

Electric Bike Specifications

Battery Bosch Lithium Ionen 36 Volt, 750Wh, with InTube Integration

Display Kiox 300 Display and LED Remote

Motor Bosch Performance CX 36 Volt, Gen 4, 250 Watt. 50-340% Assist, 85Nm

Range 30-140 miles of power assisted range, depending on terrain

Downloads

FAQs


You can see what sizes this model is available in at the top of this page.
Sizes are listed in centimeters and also specified S, M, L etc.


Note: Some models have more available sizes than others.



Next to the size options, click 'Find my size' this will allow you to input your inside leg measurement along with your height in cm. Our special size calculator will show you what size you need to order.
These are displayed in S, M & L etc to correspond with the size options.


Note: You may be a particular size on one model and a different size on another model. Please use the size calculator on each model page as sizes can vary between manufacturers and models.



You can view the stock status of any model/variant by selecting it at the top of this page. It will show you one of three stock status:


In Stock: In stock now and available to order for immediate delivery
Pre-Order: Available to pre-order with expected date of arrival shown
Sold Out: The model is completely sold out in this variant and no longer available to order


On some pre-order models, the date may show TBC. This means the supplier has not firmed up the estimated date of arrival yet.
You can order your model and we'll notify you as soon as we have further ETA's from the supplier.



If colour options are available, these will show above the size options at the top of this page.
You can click each colour to view a larger image of any colours available.


Note: Not all of our electric bikes have colour options available.



You can find the frame geometry chart in the downloads section above (if available). This is particularly handy if you want to know a specific dimension of the bike.
You can also use geometry charts to compare frame geometries to your existing bike if required too.



At e-bikeshop we specialise in the finest hand-built European eBikes. This particular model is made by Scott in Switzerland.



At e-bikeshop we work by appointment only, so we can talk to each customer on an individual basis to give the best advice possible.


We can talk you through your riding style and requirements and offer expert advice as to which model to select.


We generally keep over 150 eBikes built in our showroom. Note: Some models shown as 'Pre-Order' may not be in the showroom to view as the bike is still due from the supplier.
We can also give you the opportunity to ride a similar electric bike so you can get a feel for how electric bikes work prior to purchase.

Should you wish to purchase, we give the option to take it away that same day (subject to stock) with any accessories selected fitted and a fitting session on the bike itself by one of our eBike experts.



Yes, you may wish to collect your new electric bike from our HQ based in Farnham, Surrey.
If so please select 'Collect in store' at the checkout.


We will then prepare your new eBike and be in touch to book a suitable collection day/time.
One of our experts is on hand to help you set up the correct position on your new eBike along with answering any questions that you may have.



If you cannot find the answer you are looking for, please don't hesitate to get in touch.
Remember you can find a full F.A.Q on general electric bike & website questions by clicking here.
